GRABO Pro Brushless Suction Cup
GRABO PRO Brushless Vacuum Lifter
The GRABO PRO Brushless is GRABO’s most advanced vacuum lifter, built for professional tile contractors who handle large-format tile, gauged porcelain panels, stone, glass, metal, and other difficult materials on the jobsite. With a high-torque brushless motor, adjustable vacuum control, real-time LED display, and integrated wireless remote, it gives installers more control when lifting both heavy materials and delicate surfaces.
Features
- Brushless motor technology: High-torque brushless pump moves 30 L/min of air for quicker grabs, faster resets, and longer runtime.
- Built for pro tile handling: Ideal for large-format tile, polished porcelain, gauged panels, stone slabs, glass, metal, and other smooth or semi-porous materials.
- Adjustable vacuum control: Set the target pressure you need for the material being lifted.
- LED display: Monitor vacuum pressure in real time and make adjustments on the fly.
- Integrated wireless remote: Control the tool from up to 98 ft (30 m) away.
- 20V battery platform: Runs on the GRABO 20V battery system and includes a 2.6Ah Li-ion battery.
- Long service life: Designed for 100,000+ ON-OFF cycles or 800+ hours continuous pump service life.
- Balanced ergonomic handle: Built for better comfort during repeated lifting and placement.
- Automatic vacuum maintenance: The pump automatically maintains vacuum while moving and placing the load.
Why Tile Contractors Choose the GRABO PRO Brushless
- Better control for fragile surfaces: Adjustable suction helps reduce over-suction on thin glass, polished stone, and delicate tile.
- Strong lifting performance: Designed for both vertical and horizontal handling across multiple material types.
- Faster workflow on large tile jobs: Makes it easier to carry, position, and set oversized tile and panels.
- Works on more than just tile: Useful for glass, metal, plastic, wood, drywall, rough slate, and rough concrete within rated limits.
Best Use / Compatibility
- Best for: Professional tile contractors, stone fabricators, glass installers, and remodelers
- Ideal materials: Ceramic tile, porcelain tile, glass, stone, metal, plastic, wood, drywall, rough slate, and rough concrete within rated lift limits
- Applicable surface type: Non-porous and semi-porous materials with peak/valley height under 0.1 in (3 mm) and arc less than 5 degrees
- Important: Maximum lift and working load limit are not the same. Follow the published working load limits for the material being handled.
Lifting Capacity
| Material | Perpendicular Hold | Parallel Hold |
| Glass | 265 lbs (120 kg) | 265 lbs (120 kg) |
| Ceramic Tile | 265 lbs (120 kg) | 265 lbs (120 kg) |
| Metal | 242 lbs (110 kg) | 242 lbs (110 kg) |
| Plastic | 220 lbs (100 kg) | 220 lbs (100 kg) |
| Wood | 220 lbs (100 kg) | 143 lbs (65 kg) |
| Rough Slate | 176 lbs (80 kg) | 176 lbs (80 kg) |
| Rough Concrete | 176 lbs (80 kg) | 176 lbs (80 kg) |
| Drywall | 165 lbs (75 kg) | 143 lbs (65 kg) |
Specifications
| GRABO PRO Brushless Specifications | |
| Battery Platform | GRABO 20V 2.6Ah Li-ion, compatible with all GRABO 20V packs |
| Pump Output | 30 L/min high-flow brushless pump |
| Air Flow | 30 L/min |
| Vacuum Control | Adjustable suction limiter up to 11.6 psi (0.8 bar / 80 kPa) |
| Maximum Lifting Capacity | 375 lbs (170 kg) max lift / 265 lbs (120 kg) WLL |
| Charger Input Voltage | 100-240 VAC, 50/60 Hz |
| Battery Charging Time | Around 2 hours |
| Non-Stop Running Time | Up to 1.5 hours |
| Running Cycles on Full Charge | About 900 ON-OFF cycles of 10 seconds |
| Stand-By Mode | Up to 30 days |
| Pump Service Life | 100000+ ON-OFF cycles / 800+ hrs continuous |
| Dimensions (L x W x H) | 12.2 x 7.5 x 5.9 in (310 x 191 x 149 mm) |
| Net Weight with Battery | 4.4 lbs (2 kg) |
| Working Temperature | 32°F - 140°F (0°C - 60°C) |
| Applicable Surface Type | Non-porous and semi-porous materials with peak/valley height under 0.1 in (3 mm), arc less than 5 degrees |
| Additional Features | LED display with adjustable suction limiter and integrated wireless remote |
